Product
Chromium Copper / Beryllium Copper
-
Chromium Copper C18200 CuCr
Item Description Conductivity 80% IACS Main Components Copper(Cu) : Rem, Chromium(Cr) : 0.6 ~ 1.2% Symbol C18200 Hardness 75 HRB (Varies depending on cold working state) Tensile Strength 380 ~ 550 Mpa Yield Strength 300 ~ 450 Mpa Elongation 10 ~ 30% Application Electrical contacts, welding electrodes, high-temperature high-strength components -
Chromium Zirconium Copper C18150 CuCrZr
Item Description Conductivity 80% IACS Main Components Copper(Cu) : Rem, Chromium(Cr) : 0.5 ~ 1.5%, Zirconium(Zr) : 0.05 ~ 0.25% Symbol C18150 Hardness Approximately 75 HRB Tensile Strength Approximately 400 ~ 560 Mpa Yield Strength Approximately 320 ~ 480 Mpa Elongation Approximately 10 ~ 25% Application Welding electrodes, electrical contacts, high-temperature high-strength components -
Beryllium Copper C17510 CuNiBe
Item Description Conductivity 40% IACS Main Components Copper(Cu) : Rem, Nickel(Ni) : 1.4 ~ 2.2%, Beryllium(Be) : 0.2 ~ 0.6% Symbol C17510 Hardness 90 HRB Tensile Strength Approximately 620 ~ 860 Mpa Yield Strength Approximately 480 ~ 680 Mpa Elongation Approximately 3 ~ 10% Application Spring contacts, electrical connection components, high-strength electrical components -
High-Strength Beryllium Copper(2%) C17200 Cu2%Be
Item Description Conductivity 20% IACS Main Components Copper(Cu) : 98% 이상, Beryllium(Be) : 1.8 ~ 2.0% Symbol C17200 Hardness 35 HRB Tensile Strength Approximately 1100 ~ 1400 Mpa Yield Strength Approximately 1000 ~ 1280 Mpa Elongation Approximately 1 ~ 5% Application Spring contacts, electrical connectors, high-strength electrical components
