Product
Special Alloy Copper
-
Nickel Silver C70600 Cu10%Ni
Item Description Conductivity 10% IACS Main Components Copper (88%), Nickel (10%), Iron (1.4%) Symbol (ASTM) C70600 Hardness (HRB) 60-90 HRB Tensile Strength 379-552 MPa Yield Strength 124-345 MPa Elongation 20-30% Density 8.94 g/cm³ Applications Marine applications, desalination, heat exchangers -
Zirconium Copper C15000 CuZr
Item Description Conductivity 75-85% IACS Main Components Copper (99.6%), Zirconium (0.15-0.20%) Symbol (ASTM) C15000 Hardness (HRB) 65-100 HRB Tensile Strength 415-550 MPa Yield Strength 345-415 MPa Elongation 8-12% Density 8.89 g/cm³ Applications Electrical contacts, low-voltage current, high-conductivity components -
Cobalt Beryllium Copper C17500 CuCoBe
Item Description Conductivity 45-60% IACS Main Components Copper (97.5%), Beryllium (0.4-0.7%), Cobalt (1.8-2.0%) Symbol (ASTM) C17500 Hardness (HRB or HRC) 90-100 HRB or 20-30 HRC Tensile Strength 760-1050 MPa Yield Strength 410-760 MPa Elongation 15-25% Density 8.25 g/cm³ Applications Electrical components, mechanical components, aerospace and automotive industries -
Nickel Chromium Silicon Copper C18000 CuNiCrSi
Item Description Conductivity 45-50% IACS Main Components Copper (97%), Nickel (2-3%), Silicon (0.4-0.8%) Symbol (ASTM) C18000 Hardness (HRB or HRC) 80-90 HRB Tensile Strength 480-620 MPa Yield Strength 350-420 MPa Elongation 10-15% Density 8.3 g/cm³ Applications Electrical contacts, welding electrodes, high-current components -
Phosphorized Copper C12200 DHP
Item Description Conductivity 90% IACS Main Components Copper (99.9%), Phosphorus (0.015-0.040%) Symbol (ASTM) C12200 Hardness (HRB or HRC) 40-65 HRB Tensile Strength 205-275 MPa Yield Strength 69-140 MPa Elongation 30-45% Density 8.94 g/cm³ Applications Pipes, heat exchangers, plumbing tubes -
Oxygen-Free Copper C10400
Item Description Conductivity 100% IACS Main Components Copper (99.9% or more), Oxygen Content: Below 10ppm, Silver Content: Minimum 0.027 Symbol (ASTM) C10400 Hardness (HRB) 35-45 HRB Tensile Strength 210-275 MPa Yield Strength 69-138 MPa Elongation 30-50% Density 8.94 g/cm³ Applications Electrical conductors, wiring, electrical components -
Oxygen-Free Copper C10700 OFS
Item Description Conductivity 100% IACS Main Components Copper (99.99%), Oxygen Content: Below 5ppm, Silver Content: Minimum 0.085 Symbol (ASTM) C10700 Hardness (HRB) 40-50 HRB Tensile Strength 210-275 MPa Yield Strength 70-140 MPa Elongation 30-45% Density 8.94 g/cm³ Applications Electrical conductors, precision electronic components -
Tellurium Copper C14500 PTE
Item Description Conductivity 90% IACS Main Components Copper (99%), Tellurium (0.4-0.7%) Symbol (ASTM) C14500 Hardness (HRB or HRC) 55-75 HRB Tensile Strength 350-420 MPa Yield Strength 275-345 MPa Elongation 10-30% Density 8.94 g/cm³ Applications Machined components, electrical contacts, high-speed cutting, electrical components -
Copper Tungsten CW
Item Description Conductivity Approximately 25-30% IACS (varies by copper ratio) Main Components Copper (Cu): 30%, Tungsten (W): 70% Symbol Copper Tungsten (Cu-W 70/30) Hardness Approximately 200-250 HB Tensile Strength Approximately 650-850 MPa Yield Strength Approximately 500-700 MPa Elongation Approximately 5-15% Density Approximately 14.7-15.0 g/cm³ Applications High thermal conductivity and strength parts, electrical contacts, thermal management components, aerospace parts
