Bronze BC2 = CAC402C = C90300 | BC3 = CAC403C = C90500 | BC6 = CAC406C = C83600

Mainly used for general machinery parts, ships, and electrical mechanical structures. Used in faucet components, bearings, sleeves, bushings, gears, ship portholes, small pump parts, and general machinery parts.
Phosphor Bronze PBC2 = CAC502C = C90700 | PBC3 = CAC503C = C91000

Good corrosion and wear resistance, used for gears, worm gears, bearings, bushings, sliding parts, hydraulic cylinders, liners, and various paper-making rolls.
Aluminum Bronze ALBC2 = CAC702C = C95400 | ALBC3 = CAC703C = C95800

Used for bearings, bushings, gears, valve seats, plungers, paper-making rolls, impellers, ship bolts, nuts, and safety tools.

Classification	Type	Symbol	Old Symbol	Chemical Composition(Chemical Composition)									Relate Foregion Standards
Classification	Type	Symbol	Old Symbol	Cu	Pb	Fe	Sn	Al	Ni	Zn	Mn	P	JIS		ASTM
KSD6024, 6025													STD No	Designation	STD No	Designation
Bronze	Type 1	CAC401C	BC1C	79.0~83.0	3.0~7.0		2.0~4.0			8.0~12.0			H5102	BC1C		C84400
	Type 2	CAC402C	BC2C	86.0~90.0			7.0~9.0			3.0~5.0				BC2C		C90300
	Type 3	CAC403C	BC3C	86.5~89.5			9.0~11.0			1.0~3.0				BC3C		C90500
	Type 6	CAC406C	BC6C	83.0~87.0	4.0~6.0		4.0~6.0			4.0~6.0				BC6C		C83600
	Type 7	CAC407C	BC7C	86.0~90.0	1.0~3.0		5.0~7.0			3.0~5.0				BC7C		C92200
PhosphorBronze	Type 2	CAC502C	PBC2C	87.0~91.0			9.0~12.0					0.05~0.5	H5113	PBC2C		C90700
PhosphorBronze	Type 3	CAC503C	PBC3C	84.0~88.0			12.0~15.0					0.05~0.5	H5113	PBC3C		C91000
Aluminum Bronze	Type 1	CAC701C	ALBC1C	85.0~90.0		1.0~3.0		8.0~1.0	0.1~1.0		0.1~1.0		H5114	ALBC1C	B148	C95200
	Type 2	CAC702C	ALBC2C	80.0~88.0		2.5~5.0		8.0~10.5	1.0~3.0		1.0~1.5			ALBC2C		C95400
	Type 3	CAC703C	ALBC3C	78.0~85.0		3.0~6.0		8.5~10.5	3.0~6.0		0.1~1.5			ALBC3C		C95800
